Objectives
Test the product space radiation characteristics
Criteria
Refer GB/T 9410,YD/T 1059
Parameter:
Equipment Name: Multi-probe spherical near-field measurement system
Darkroom Size: 5000mm×5000mm×5000mm
Shielding Effectiveness: -100dB
Measuring Frequency: 0.4~6GHz
Dynamic Range: -60dB
loading capacity: 100kg
Probes:64
measurement loop Diameter: 3.2m
Oversampling pendulum Angle: ±8°
Objectives
Verify product intermodulation characteristics
Criteria:
Refer GB/T 9410,YD/T 1059
Parameter:
Equipment Name: intermodulation testing
Size: 3500mm×3500mm×3500mm
Output Power: 0-20W
FREQUENCY RANGE: 400MHz--6000MHz
Temperature : 15℃~35℃
"Barometric pressure:86kPa~106kPa"
Relative Humidity : 45%~75%
Objective:
Check that no arc phenomenon or broadband noise is less than or equal to -107dbm /200K under high power signal input
Criteria:
Refer GB/T 9410,YD/T 1059
Parameter:
Equipment Name: High power rf test platform
Darkroom Size: 3500mm×3500mm×3500mm
Instruments and apparatus:Spectrometer, amplifier, signal source
Output Power: 0-100W
Frequency Range: 400MHz--6000MHz
Temperature: 15℃~35℃
Barometric pressure: 86kPa~106kPa
Relative humidity: 45%~75%
Objectives:
Verify whether the radome and sealant can withstand light radiation for a long time without performance degradation
Criteria:
Refer GB/T 2423.24,IEC 68-2-5,GB/T 9410,YD/T 1059
Parameter:
Equipment Name: wave length
Nominal volume: 200L
UV (Ultraviolet) Oven: 280~350nm
Intensity of uv irradiation: 1120W/m2
Temperature: 50±3℃
