| Electrical Specifications |
| Frequency Range,MHz | 1695-1880 | 1850-1990 | 1920-2170 | 2300-2500 | 2490-2690 |
| Polarization | ±45° |
| Gain,dBi | 21.3±1 | 22±1 | 22.5±1 | 23±1 | 23.5±1 |
| Beam Width(3dB),H,deg | 12±4 |
| Beam Width(3dB),V,deg | 8±2.5 |
| USLS(First Lobe),dB | ≥15 |
| Front-To-Back Ratio,180°±30°,dB | ≥25 |
| VSWR | <1.5 |
| Isolation,dB | ≤-25 |
| Intermodulation IM3,dBc | ≤-150 |
| Impedance,Ω | 50 |
| InputPower,MAX,Watt | 200 |
| Mechanical Specifications |
| Connector | 4.3-10 Female×2 |
| Dimensions L×W,mm | 1300×850 |
| Packed Dimensions,mm | 890×345×835 |
| Weight,kg | 13.5 |
| Packed Weight,kg | 16.5 |
| Down Tilt Continuous Range,° | -5°~5° |
| Operational Max Wind Speed,km/h | 200 |
| Mounting Method | Pole Mounting |
| Operating Temperature,℃ | -50～+65 |
